DC power adapter 12V1A with C-tick
Item No.: IN1201000
  Features/ Functions



  • DC power adapter regulated 12V 1A output with low ripple
  • Power-on LED indicator
  • Comply with EMPS
  • Certifications: SAA, C-tick, RoHS

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 12VDC +/-5%
  • Output current : 1A
  • Ripple : 250 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85 % Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
