Mini power adapter 9V0.6A CE
Item No.: IN0900600
Features/ Functions
Mini power adapter r
egulated output with low ripple
Power-on LED indicator
Comply with ErP
Certifications: GS, CE, BS, CB, EMC, RoHS
General Specifications
Input :100-240VAC, 50/60Hz
Output voltage : 9 VDC +/-5%
Output current : 600 mA
Ripple : 100 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 70 % Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
