Single cell Lithium Ion battery charger 4.2V 2A UL |
Item No.: IN0422000 |
|
|
Features/ Functions |
- Smart 3 stage 3.6V lithium ion battery charger
- Constant charging current /voltage
- Terminate charging once battery is full
- LED indicate the charge status
- Comply with ENERGY STAR regulations
- Safety standard approvals: UL, CUL, PSE, CB, FCC
|
|
 |
|
|
General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 2.5~4.2 VDC
- Output current : 2A +/-5%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 75% Min.
- Operating temperature: -29℃~+45.5℃
- Storage temperature: -40℃~+75℃
- Operating relative humidity: 5%~95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|

 |
|
 |
|
