Lithium battery charger 16.8V 6A UL CE
Item No.: IN1686000
  Features/ Functions



  • Smart lithium battery charger 4S cell 16.8V
  • Constant charge current
  • Stop charge once the battery pack is full
  • Dual color LED indicate the charge status
  • Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 10~16.8 VDC
  • Output current : 6A +/-600mA
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
