| LED power supply driver 36V 3A |
| Item No.: IN3603000 |
|
|
| Features/ Functions |
|
- 36V LED strip power supply regulated output with low ripple
- Constant output current
- With power factor control
- Power on LED indicator
- Certifications: UL, CUL, GS, CE, BS, SAA, RCM, EK, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 22 ～ 36VDC
- Output current : 3A +/-5%
- Ripple : 360 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Power factor: > 0.9
- Efficiency: 88% the Min.
- Operating temperature: -29℃ ～+45.5℃
- Storage temperature: -40℃ ～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- Warranty: 3 year
|
|
|
 |
|
 |
|
