| USB charger 6V600mA CE |
| Item No.: IN0600600 |
|
|
| Features/ Functions |
- Regulated output with low ripple
- Power-on LED indicator
- Modified and custom designs
- Comply with ENERGY STAR
- Certifications: GS, CE, CB, EMC, RoHS
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 6 VDC
- Output current : 600 mA
- Ripple : 50 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 75 % Min.
- Operating temperature: -29℃～45.5℃
- Storage temperature: -40℃～75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; NIN 2.5
|
|
|
 |
|
 |
|
