MCU Ni mh battery charger 9V 1.5A 6 series cell UL
Item No.: IN0901500
  Features/ Functions
  • MCU 6S Cell Ni mh battery charger
  • Automatic detection of shorted/ bad battery
  • LED indicate the charge status
  • Safety standard approvals: UL, CUL, PSE, CB, FCC

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 4.8~9VDC
  • Output current : 1.5A
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80% Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ~+45.5℃
  • Storage temperature: -40℃ ~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
