| 3 stage Lithium battery charger 8.4V 3A |
| Item No.: IN0853000 |
|
|
| Features/ Functions |
- For Lithium battery charger
- Constant charging current
- Lowering voltage once charge completed
- With a dual color LED charging status indicator
- Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Charging voltage : 5～ 8.5 VDC
- Charging current : 3A +/-5%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85% Min
- Temperature: Case 75 ℃ Max.
- Operating temperature: -29℃ ～ +45.5℃
- Storage temperature: -40℃ ～ +75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
