| MCU automatic Ni-mh Battery charger 12S 18V 2A |
| Item No.: IN1802000 |
|
|
| Features/ Functions |
|
- MCU controls the whole charge process and guarantees the battery pack is fully charged, and also avoids battery pack over charge.
- Automatic detection of shorted/ bad battery
- LED indicate the charge status
- Safety standard approvals: UL, CUL, GS, CE, SAA, PSE, FCC, EMC, RCM, RoHS
- Application: suitable for 12 series cell ni-mh battery pack
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 9.6 ～18VDC
- Output current : 2000 mA +/-200
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 80% Min
- Dielectric withstand test: 5mA3000VAC for 60 seconds
- Temperature: Case 65 ℃ Max.
- Operating temperature: -29℃ ～+45.5℃
- Storage temperature: -40℃ ～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
