Intelligent charger for Li-ion battery 21V 0.5A
Item No.: IN2100500
  Features/ Functions
  • Intelligent battery charger for 5 cell Li-ion battery pack
  • Constant charging current
  • Lowering voltage to terminate charge once battery is full
  • LED indicate the charge status
  • Comply with MEPS
  • Safety standard approvals: SAA, CB, C-tick

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 15～ 21 VDC
  • Output current : 500 mA +/-50
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 73% Min.
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -29℃ ～ +45.5℃
  • Storage temperature: -40℃ ～ +75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
