Lithium-ion battery charger 58V 2A |
Item No.: IN5802000 |
|
|
Features/ Functions |
- Smart Lithium-ion battery charger for 14 series cell
- Constant charging current
- Terminating charge once battery is full
- 2 color LED indicating charging status
- Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 36 ~ 58 VDC
- Output current : 2A +/-5%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency : 88% Min.
- Temperature: Case 75 ℃ Max.
- Operating temperature: -29℃ ~ +45.5℃
- Storage temperature: -40℃ ~ +75℃
- Operating relative humidity: 5%~95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- Overheat protection design
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|

 |
|
 |
|
