| 7.4V Li-ion battery charger 2A UL 18650 battery |
| Item No.: IN0852000 |
|
|
| Features/ Functions |
- Li-ion battery charger 7.4V 2 series cell 18650
- Constant charge current
- Terminating the charge once battery is full
- With a dual color LED indicator
- Comply with ENERGY STAR requirements
- Safety standard approvals: UL, CUL, PSE, CB, FCC
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Charging voltage : 5～8.5 VDC
Charging current: 2A+/-200 mA
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80% Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty : 3 years
|
|
|
 |
|
 |
|
