| Universal charger for power tool battery 21V1.5A |
| Item No.: IN2101500 |
|
|
| Features/ Functions |
- Universal charger for power tool battery
- Continuously monitoring battery voltage
- Constant output current to provide protection
- Terminating the charge once battery is full
- With a dual color LED indicator
- Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 12.5～ 21VDC
- Output current : 1.5A+/-0.15A
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85 Min.
- Temperature: Case 75 ℃ Max.
- Operating temperature: -29℃ ～ +45.5℃
- Storage temperature: -40℃ ～ +75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short-circuit protection: Auto recovery
- Overheat protection design
- MTBF: 30000 hours full rated load operation at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warrenty: 3 year
|
|
|
 |
|
 |
|
