| Switching power supply 21V5A |
| Item No.: IN2105000 |
|
|
| Features/ Functions |
-
Switching power supply universal input voltage
- With a power-on LED indicator
- Constant output current option
- Comply with ENERGY STAR requirements
- Certifications:UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
- Complete with AC power cable
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 21VDC +/-5%
- Output current : 5000 mA
- Ripple : 500 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85 % Min
- Temperature: Case 75 ℃ Max.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
