| 24V electric scooter battery charger |
| Item No.: IN2902000 |
|
|
| Features/ Functions |
- 24V electric scooter battery charger 2 cell Lead acid battery
- Continuously monitoring battery voltage
- Constant charging current /Voltage
- Terminating charge once battery is full
- With a dual color LED charging status indicator
- Comply with ENERGY STAR requirements
- Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage: 18～ 29.8 VDC
- Output current: 2A+/-0.2A
- Inrush current: Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85% Min.
- Temperature: Case 75 ℃ Max.
- Operating temperature: -29℃ ～ +45.5℃
- Storage temperature: -40℃ ～ +75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short-circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
