| Smart charger for 6V Lead acid battery |
| Item No.: IN0751500 |
|
|
| Features/ Functions |
- Reverse polarity protection
- Continuously monitoring battery voltage
- Constant charging current
- Terminating charge once battery is full
- With a dual color LED indicator for charging status
- Safety standard approvals: SAA, CB, C-tick
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 6～7.8VDC
- Output current: 1.5A+/_0.15A
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 70 % Min.
- Temperature: Case 65 ℃ Max.
- Operating temperature: -29℃ ～ +45.5℃
- Storage temperature: -40℃ ～ +75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short-circuit protection: Auto recovery
- Overheat protection design
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; NIN 2.5
|
|
|
 |
|
 |
|
