Li-ion battery charger 12.6V 1A PSE |
Item No.: IN1261000 |
|
|
Features/ Functions |
- Smart 12.6V Li-ion battery charger for 3 series cell pack
- Constant charge current
- Terminate the charge once battery is full
- With a dual color LED indicator
- Safety standard approvals: PSE, UL, CUL, CB, FCC
|
|
 |
|
|
General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage: 9~12.6VDC
- Output current: 1A+/-10%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 80 % Min.
- Temperature: Case 65 ℃ Max.
- Operating temperature: -29℃ ~ +45.5℃
- Storage temperature: -40℃ ~ +75℃
- Operating relative humidity: 5%~95% RH
- Over load protection: Auto recovery
- Short-circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|

 |
|
 |
|
