| 4 series cell 12V LiFePO4 battery charger 14.6V |
| Item No.: IN1503000 |
|
|
| Features/ Functions |
- 12V LiFePO4 smart battery charger for 4 series cell
- Continuously monitoring battery voltage
- Constant charge current
- Terminating charge once battery is full
- With a dual color LED indicator
- Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 8～14.6 VDC
- Output current : 3A +/-5%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85 % Min.
- Temperature: Case 65 ℃ Max.
- Operating temperature: -29℃ ～ +45.5℃
- Storage temperature: -40℃ ～ +75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short-circuit protection: Auto recovery
- Overheat protection design
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
| FL5, No.62, Liusha S. RD., Shijie,Dongguan, Guangdong 523303 China 广东省东莞市石碣镇刘沙南路62号5层 |
| Tel：+86(0)769-81812289 Fax：+86(0)769-81812989 E-mail: william@intaia.com Website: Http://www.intaia.com |
|
