Electric bike battery charger 48V 2A LiFePO4 |
Item No.: IN4802000 |
|
|
Features/ Functions |
Automatic LiFePO4 electric bike battery charger LiFePO4 13 cell
Continuously monitoring the battery voltage
Constant charging current
Terminating the charge once battery is full
LED indicate the charge status
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, RCM, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 26~48 VDC
Output current : 2A +/-200mA
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85 % Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
Overheat protection design
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
