E-bike single Lead acid battery 12V charger
Item No.: IN1504000
  Features/ Functions
  • Smart E-bike Lead acid battery charger
  • Continuously monitoring the battery voltage
  • Constant charging current
  • Terminating the charge once battery is full
  • With a dual color LED charging status indicator
  • Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 9 14 VDC
  • Output current :  4A+/-0.4A
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Temperature: Case 75  Max.
  • Operating temperature: -29 +45.5
  • Storage temperature: -40 +75
  • Operating relative humidity: 5%95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 35
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty : 3 year
