| AC adapter 22.5V1.25A for Roomba vacuum cleaner |
| Item No.: IN2251250 |
|
|
| Features/ Functions |
|
Designed for Roomba Vacuum cleaning robot 500 series
Constant current output with low ripple
Power-on LED indicator
Certifications: PSE, UL, SAA, EMC, FCC, C-tick,RoHS
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 22.5 VDC
- Output current : 1.25A
- Ripple : 250 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85 % Min
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
|
 |
|
 |
|
