Power supply 19V 6A for laptop HP/Dell |
Item No.: IN1906000 |
|
|
Features/ Functions |
Power supply regulated output 19V with low ripple
High efficiency & long life
With power factor correction
Suitable for Laptops of various brand
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 19 VDC +/-5%
Output current : 6A
Ripple : 190 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Power factor: > 0.9
Efficiency: 85 % Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
