150W LED power supply 51V
Item No.: IN5103000
  Features/ Functions
  • LED power supply for LED light
  • Constant output current
  • Power factor control
  • Comply with CEC ,MEPS, EuP
  • Certifications: UL, CUL, GS, CE, BS, SAA, RCM, PSE, CB, FCC, EMC, C-tick, RoHS
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 45~51 VDC
  • Output current : 3A +/-5%
  • Ripple : 500 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • Dielectric withstand test: 5mA 3000Vac for 2 seconds
  • No load standby power ≤0.5W
  • Efficiency: 88% Min.
  • Power factor :>90%
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Warranty: 3 year
