Regulated power supply 18V160W
Item No.: IN1809000
  Features/ Functions
  • Regulated power supply with low ripple
  • Active power factor correction
  • Comply with CEC ,MEPS, EuP
  • Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
    •
      General Specifications
    • Input :100-240VAC, 50/60Hz
    • Output voltage : 18 VDC +/-5%
    • Output current : 9A
    • Ripple : 350 mVp-p Max.
    • Inrush current : Limited 15A for a cold start
    • Dielectric withstand test: 5mA3000Vac for 2 seconds
    • No load standby power ≤0.75W
    • Efficiency: 88% Min.
    • Power factor:>0.88
    • Temperature: Case 75 ℃ Max.
    • Operating temperature: -29℃～+45.5℃
    • Storage temperature: -40℃～+75℃
    • Operating relative humidity: 5%～95% RH
    • Over load protection: Auto recovery
    • Short circuit protection: Auto recovery
    • MTBF: 30000 hours full rated load operation at 25℃
    • AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
    • Warranty: 3 year
