| 18V 18650 Li ion battery charger |
| Item No.: IN2101000 |
|
|
| Features/ Functions |
- Smart 18650 Li ion battery charger 18V
- Continuously monitoring the battery voltage
- Constant output current
- Terminating charging once battery is full
- With a dual color LED indicator
- Comply with ENERGY STAR requirements
- Safety standard approvals: UL, CUL, PSE, CB, FCC
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 12.5～21 VDC
Output current: 1+/-0.1A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 years
|
|
|
 |
|
 |
|
