24V700mA power supply driver LED TUV/GS
Item No.: IN2400700
  Features/ Functions
  • Power supply 700mA driver LED
  • With a power on LED indicator
  • High efficiency complying with ErP
  • Certifications: GS, CE, CB, EMC, RoHS
    •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 24 VDC +/-5%
  • Output current: : 700 mA
  • Ripple : 350 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80% the Min.
  • Operating temperature: -29℃～+45.5℃
  • Storage temperature: -40℃～+75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Warranty: 3 years
    		•
