AC DC power adapter 12V2A CE |
Item No.: IN1202000 |
|
|
Features/ Functions |
- AC DC power adapter regulated output 12v with low ripple
- With power-on LED indicator
- Long life & high reliability
- Compliant with ErP regulations
- Certifications: GS, CE, BS, CB, EMC, RoHS
|
|
 |
|
|
General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 12 VDC +/-5%
- Output current : 2A
- Ripple : 250 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 80% Min.
- Operating temperature: -29℃~+45.5℃
- Storage temperature: -40℃~+75℃
- Operating relative humidity: 5%~95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 35℃
- AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 years
|
|
|

 |
|
 |
|
