Electric scooter charger 48V 2A LiFePO4 battery |
Item No.: IN5802000 |
|
|
Features/ Functions |
3 stage smart electric scooter charger for 48V rechargable lifepo4 battery
Continuously monitoring battery voltage
Constant charging current
Terminating charge once battery is full
LED indicate the charge status
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 40~59.5 VDC
Output current : 2A +/-2A
Loading: 3.7V x 12 series LiFePO4 batteries
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85 % Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
