Automatic Li-ion battery charger 14.8V 1A BS
Item No.: IN1681000
  Features/ Functions
  • Smart 16.8V Li-ion battery charger for 4S rechargeable battery
  • Constant charging current and voltage
  • Terminate charge once battery is full
  • With a dual color LED indicator red for charging green for charged
  • Comply with ErP
  • Safety standard approvals: BS, CE, GS, EMC

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 10～16.8+/-0.2VDC
  • Output current: 1+/-0.1A
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency : 80% Min.
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -29℃ ～ +45.5℃
  • Storage temperature: -40℃ ～ +75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
    		•
