Automatic Lead acid battery charger 29.4V 4A
Item No.: IN2904000
  Features/ Functions
  • Automatic battery charger for 2 series cell Lead acid battery
  • Constant charging current for fast charging
  • Terminate charge once battery is full
  • A dual color LED displays red for charging / green for finish
  • Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage: 18~29.4+/-0.5VDC
  • Output current: 4A+/-0.4A
  • Inrush current: Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -29℃ ~+45.5℃
  • Storage temperature: -40℃ ~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
