LED power transformer 29V0.3A SAA
Item No.: IN2900300
  Features/ Functions
  • Power transformer for LED light
  • Constant current output
  • With a power-on LED indicator
  • Comply with MEPS requirements
  • Certifications: SAA, C-tick, RCM
    •
      General Specifications
    • Input :100-240VAC, 50/60Hz
    • Output voltage : 24 ～ 29 VDC
    • Output current : 300 mA +/-5%
    • Ripple : 250 mVp-p Max.
    • Inrush current : Limited 15A for a cold start
    • No load standby power ≤0.5W
    • Efficiency:  80% Min.
    • Temperature: Case 65 ℃ Max.
    • Operating temperature: -29℃～+45.5℃
    • Storage temperature: -40℃～+75℃
    • Operating relative humidity: 5%～95% RH
    • Over load protection: Auto recovery
    • Short circuit protection: Auto recovery
    • MTBF: 30000 hours full rated load at 25℃
    • Warranty : 3 year
