| 11.1V Li-ion battery charger |
| Item No.: IN1260500 |
|
|
| Features/ Functions |
- Smart li-ion battery charger 11.1V 3 series cell
- Continuously monitoring the battery voltage
- Constant charging current
- Terminating charging once battery is full
- LED indicate the charge status
- Comply with ENERGY STAR
- Safety standard approvals: UL, CUL, PSE, FCC
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage: 7.5～12.6 VDC
Output current: 0.5A +/-5%
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency : 80% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 years
|
|
|
 |
|
 |
|
