4S cell Lead acid battery charger 58.4V 2A |
Item No.: IN5802000 |
|
|
Features/ Functions |
Automatic 3 stage battery charger
Continuously monitoring battery voltage
Constant charging current /voltage
Terminate charge once battery is full
With a dual color LED charging status indicator
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 36~58.8 VDC
Output current : 2A+/-0.2A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ~+45.5℃
Storage temperature: -40℃ ~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warrenty: 3 year
|
|
|
|

 |
|
 |
|
