iRobot Scooba power supply 380 6050 Model 13143
Item No.: IN2201750
Features/ Functions
Charge Scoobas battery in just three hours! Plug directly into the robot or use with the Scooba Charging Base
With an additional power supply, charge two batteries simultaneously
iRobot Scooba floor vacuum power supply 13143 replacement
With a power-on LED indicator
Certifications: UL, cUL, PSE, GS, CE, SAA, EMC, FCC, C-tick, RoHS
General Specifications
Input :100 ～240VAC, 50/60Hz
Output voltage : 5 ～22VDC
Output current : 1.75A +/-5%
Ripple : 250 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85 % Min
Operating temperature: -29℃～+45.5℃
Storage temperature: -40℃～+75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty : 3 year
