Led driver for aquarium light 44V1.4A SAA |
Item No.: IN4401500 |
|
|
Features/ Functions |
Led driver for aquarium light
Constant output current
Comply with CEC, MEPS, EuP
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 32 ~ 44VDC
Output current : 1.4A +/-5%
Ripple : 450 mVp-p Max.
Inrush current : Limited 15A for a cold start
Dielectric withstand test: 5mA 3000Vac for 2 seconds
No load standby power ≤0.5W
Efficiency: 87% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Warranty: 3 year
|
|
|

 |
|
 |
|
