36V Smart electric bike battery charger |
Item No.: IN4401000 |
|
|
Features/ Functions |
Universal AC input
Suitable for 3 series cell Lead acid battery pack 36V
Constant current and voltage( CC, CV mode)
Terminateng the charge once battery is full
Dual color LED indicates the charge status
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 27~ 44VDC
Output current : 1A+/-100
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
Application: Electric bike, scooter
|
|
|

 |
|
 |
|
