Battery charger for single Li-ion 3.7V 18650 SAA
Item No.: IN0422000
  Features/ Functions
  • Smart 3-step li ion battery charger
  • Constant charging current
  • Terminating the charge once battery pack is full
  • Dual color LED indicating charging status
  • Standard approvals: SAA, RCM, C-tick, RoHS
  • High reliability & long life
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 2.5 ~4.2 VDC
  • Output current : 2A +/-5%
  • No load standby power ≤0.5W
  • Efficiency : 65% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
