| 12V 1A power supply PSE approved |
| Item No.: IN1201000 |
|
|
| Features/ Functions |
|
12V 1A power supply regulated output with low ripple
Power-on LED indicator
Efficiency Level: V
Certifications: PSE, UL, cUL, FCC
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 12 VDC +/-5%
- Output current : 1A
- Ripple : 120 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 82 % Min.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 years
|
|
|
 |
|
 |
|
