6V intelligent Lead acid battery charger UL PSE
Item No.: IN0751000
  Features/ Functions
  • Intelligent Lead acid battery charger
  • Sensing and following battery voltage
  • Constant current and voltage (CC,CV mode)
  • Stopping charging once batteries become full
  • 2 color LED indicating charging status
  • Safety standard approvals: UL, CUL, CCC, PSE, CB, FCC
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 5 ~ 7.5 VDC
  • Output current : 1A +/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 75% Min.
  • Operating temperature: -29℃ ~+45.5℃
  • Storage temperature: -40℃ ~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warrenty: 3 year
