2 series cell Lead acid battery charger CE 29V0.5A
Item No.: IN2900500
  Features/ Functions
  • Smart battery charger 3 stage
  • Sensing and following battery voltage
  • Constant current and voltage (CC,CV mode)
  • Stopping charging once batteries become full
  • 2 color LED indicating charging status
  • Safety standard approvals: GS, CE, CB, EMC
    •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 16 ～ 29.8 VDC
  • Output current : 0.5A +/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 75% Min.
  • Operating temperature: -29℃ ～+45.5℃
  • Storage temperature: -40℃ ～+75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
