| 18650 Lithium-Ion Charger 4 series cell 16.8V1A |
| Item No.: IN1681000 |
|
|
| Features/ Functions |
|
For battery pack of 4S cell Li-ion battery pack
Constant charging current /voltage
Terminate charging once battery is full
With a dual color LED indicator for charger status
Comply with CEC efficiency V
Safety standard approvals: UL, cUL, PSE, FCC
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage: 10～16.8 +/-0.2VDC
Output current: 1+/-0.1A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|
|
 |
|
 |
|
