Power adapter for LED light 12V1.5A GS/CE
Item No.: IN1201500
  Features/ Functions
  • Power adapter for LED light TUV/GS approval
  • Constant output current
  • Power on LED indicator
  • Comply with ErP regulations
  • Certifications: GS, CE, CB, EMC, RoHS
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 9 ~12VDC
  • Output current : 1.5A +/-5%
  • Ripple : 120 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80% the Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
