6 cell Li-ion battery charger 25.5V 100W
Item No.: IN2554000
  Features/ Functions
  • 3 stage smart charger
  • Continuously monitoring battery voltage
  • Constant output current to provide protection
  • Terminating the charge once battery is full
  • With a dual color charging status indicator
  • Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 12.5 ~25.2 VDC
  • Output current : 4A +/-400mA
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency:85% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
