36V Lead acid battery charger
Item No.: IN4401500
  Features/ Functions
  • Smart 3 stage battery charger 36V
  • Continuously monitoring battery voltage
  • Constant charging current
  • Terminate charge once battery pack is full
  •  A dual color LED indicate the charge status
  • Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 27~44VDC
  • Output current : 1.5A+/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85 % Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ~ +45.5℃
  • Storage temperature: -40℃ ~ +75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
