| AC power supply 19V 3A for Trimble battery charger |
| Item No.: IN1903000 |
|
|
| Features/ Functions |
|
AC power supply 19V regulated output with low ripple
Power-on LED indicator
Comply with CEC,MEPS,EuP
Certifications: UL, CUL, GS, CE, BS, SAA, RCM, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 19 VDC +/- 5%
Output current : 3A
Ripple : 250 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85 % Min.
Operating temperature: -29℃～+45.5℃
Storage temperature: -40℃～+75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|
 |
|
 |
|
