Automatic battery charger li ion 25.2V 0.5A UL |
Item No.: IN2550500 |
|
|
Features/ Functions |
3 stage li ion battery charger for 6S cell
Constant charge current / voltage
Terminate charge once battery pack is fully charged
With a dual color LED indicates the charge status
Comply with CEC efficiency V
Safety standard approvals: UL, cUL, PSE, FCC
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage: 15~25.2VDC +/-0.2
Output current: 0.5+/-0.1A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 years
|
|
|

 |
|
 |
|
