lithium polymer battery charger 12.6V 5A |
Item No.: IN1265000 |
|
|
Features/ Functions |
Battery charger for 3 series cell lithium polymer
Constant charge current
Terminate charge once the battery pack is full
LED indicate the charge status
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 7.5~ 12.6VDC
Output current : 5A+/-0.5A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
|
|
|

 |
|
 |
|
