26650 battery charger 5S cell 21V 5A liion charger |
Item No.: IN2105000 |
|
|
Features/ Functions |
Smart 26650 battery charger
Constant charging current
Stop charge once battery pack is full
With a dual color LED indicate charge status
Safety standard approvals: UL, CUL, GS, CE, BS, SAA, RCM, EK, PSE, CB, FCC, EMC, C-tick
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage: 12.5 ~ 21VDC
Output current: 5A +/-0.5A
Inrush current: Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 90% Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty : 3 year
|
|
|

 |
|
 |
|
