Quality power supply 18vdc power adapter 18v 2.5a
Item No.: IN1802500
  Features/ Functions
  • Power supply regulated 18V constant voltage 45W
  • LED indicator for power-on
  • CEC ,MEPS, ErP approved
  • Certifications: UL, CUL, GS, CE, BS, SAA, RCM, PSE, CB, FCC, EMC, C-tick, RoHS
  •
      General Specifications



  • Input :100~240VAC, 50/60Hz
  • Output voltage:18 VDC +/-5%
  • Output current: 2.5A
  • Ripple: 200 mVp-p Max.
  • Inrush current: Limited 15A for a cold start
  • Dielectric withstand test: 5mA 3000Vac for 2 seconds
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
