LiFePO4 battery charger 2S cell pack 7.3V 2A |
Item No.: IN7502000 |
|
|
Features/ Functions |
Intelligent LiFePO4 Battery Pack Charger 6V 12v 16v 24v 36v 48v charger
Constant charge current for fast charge
Terminate charge once battery is full
Dual color LED indicator for the charge status
Safety standard approvals: UL, CUL, PSE, CB, FCC
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 4~7.3VDC
Output current : 2A +/-200mA
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 75% Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
