LiFePO4 battery charger 2S cell pack 7.3V 2A
Item No.: IN7502000
  Features/ Functions
  • Intelligent LiFePO4 Battery Pack Charger 6V 12v 16v 24v 36v 48v charger
  • Constant charge current for fast charge
  • Terminate charge once battery is full
  • Dual color LED indicator for the charge status
  • Safety standard approvals: UL, CUL, PSE, CB, FCC
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 4~7.3VDC
  • Output current : 2A +/-200mA
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 75% Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ~ +45.5℃
  • Storage temperature: -40℃ ~ +75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
